Stepper motor with integrated controller
Holding torque: 0.6 to 1.75 Nm
Flange size: Nema 23
Interfaces: Profibus, CANopen or Digital I/O
Housing: Standard
Connector outlet: radial or axial
Connection: Sub-D connector 15-pin HD + 1x Sub-D 9-pin radial or axial
Stepper motor with integrated Nema23 controller
The Colibri compact drive is the basis of our products - the controller is permanently connected to the motor to form a compact unit. Positioning control with program memory, power output stage and an integrated encoder are combined in a compact housing to form an easy-to-install unit.
Technical details:
Control voltage: + 24VDC
Motor voltage: + 24 to +48 VDC
Max. phase current: adjustable up to 3A
Shaft diameter: 6.35 mm
Interfaces: Profibus, CANopen or Digital I/O
Holding torque: 0.6 - 1.75Nm
Temperature range: 0 to + 50°C
Current reduction: adjustable
Inputs/outputs: 2xoutput/6x input (24V)
Dynamic switching of step resolution: 1/8 1/4 1/2 1/1
Housing variants: Standard
| Delivery time | 1-2 week |
|---|---|
| Motor size stepper motors | NEMA23 |
| Controller | SPS-I/O, ProfiBus |
| Encoder | Inkremental |
| Brake | without Brake, with Brake |
